Mill gears

Raw material and mining industry

Robust and reliable: Each of our mill gearboxes is designed for years of permanent use with minimal maintenance intervals. Due to our long-standing activity in this transmission sector, we have ready-made solutions for various mill sizes.

Gearboxes for ball mills

Mill size / type Nominal power in kW Type of gear Gear ID Unit weight in kg Substitute for gearbox
Ø 2.0 x 10.5 m
Ball mill
500 Spur wheel gearbox MS050D36 15,850
Ø 2.7 x 5.5 m
Ball mill
550 Spur wheel gearbox MS055B73 10,800 D3PSF140
Ø 2.6 x 13 m
Ball mill
1,000 Spur wheel gearbox MS100H20 23,000 A2800
ZTB-1250-2000
ZD-340
Ø 2.6 x 13 m
Ball mill
1,000 Spur wheel gearbox MS100D37 21,600 ZD4-340
ZD3400
A2800
D3500
Ø 2.6 x 13 m
Ball mill
1,250 Spur wheel gearbox MS125D37 25,500 ZD4-340
ZD3400
A2800
D3500
Ø 3.0 x 14 m
Ball mill
1,600 Spur wheel gearbox MS160C54 34,500 D3600
ZM1600
40A7-4300
Ø 4.0 x 13.5 m
Ball mill
3,200 Spur wheel gearbox MS320F31 61,500 A3600
A4000
Ø 4.0 x 13.5 m
Ball mill
3,200 Planetary gearbox MP320F32 48,000 A3600
A4000
Ø 4.6 x 15 m
Ball mill
4,250 Planetary gearbox MP425C66 66,800 A3600
A4000

Gearboxes for SAG mills

Mill size / type Nominal power in kW Type of gear Gear ID Unit weight in kg Substitute for gearbox
Ø 5.5 x 2.5 m
SAG mill
1,350 Spur wheel gearbox MS135B06 3,100 D2PSF90
Ø 9.75 x 5.0 m
SAG mill
8,000 Spur wheel gearbox MS800C06 17,500 MDSS 02
Ø 7.3 x 13.0 m
SAG mill
8,000 Spur wheel gearbox MS800D05 21,500
Ø 7.9 x 13.7 m
SAG mill
8,500 Spur wheel gearbox MS850D05 22,300

Your advantages

  • Customized solution
  • End-to-end service: from the design, manufacture, testing and commissioning at your premises to after-Sales- service (maintenance/servicing/repairs) - all from one company
  • Fast, direct consultation with experienced project teams
  • Regular status updates during the production of your gearboxes
  • Remote gearbox maintenance with our Condition Monitoring System: GearView
Mill gearbox MS100D37
Mill gearbox MS100D37
Mill gearbox MS320F31
Mill gearbox MS320F31
Mill gearbox MS100D37
Mill gearbox MS100D37
Mill gearbox MS320F31
Mill gearbox MS320F31
Mill gearbox MS320F31
Mill gearbox MS320F31
mill gearbox MS055B73
mill gearbox MS055B73
